Image preview - the first page of the document



>> Download quart2 documenatation <<

Text preview - extract from the document

RE-50                                        BODY PANEL REPLACEMENT

     QUARTER WHEEL HOUSING OUTER PANEL
     (CUT): 5-Door Left Side
REMOVAL (With the quarter panel removed.)


                           --3             --3
                                                               --8
                                                 --2
                     --2




                     --3
                                                                      -- 11
      Cut and Join                     --1
      Location



          50 mm




                                                   --3
                                     --4


                                                                      --6


                                                                              --4




     mm              in.
     50           1.97

1.    Cut and join the parts at the location as shown above.
                                           BODY PANEL REPLACEMENT                                                   RE-51
INSTALLATION


                         --4               --1
                                                 --3
                                                              -- 11
                                                  --2
                   --2




                   --4
                                                                                   -- 15
            Butt Weld                    --1




                                                                               Assembly Mark




                                        --6             --3


                                                                                    --6




                                                                                            --4




1.   Determine the position of the new parts by the assem-    2.      Before welding the new parts, temporarily install the
     bly marks of the inner and outer panels.                         quarter panel and check the fit.
