Image preview - the first page of the document
quarterw


>> Download quarterw documenatation <<

Text preview - extract from the document
RE-46                                         BODY PANEL REPLACEMENT

     QUARTER WHEEL HOUSING OUTER PANEL
     (CUT): Right Side
REMOVAL (With the quarter panel removed.)



                                                   --3
                                 --9
                                             --2                    --2

                                                                    --2


                                                                          --2
                                                                           --3
                       --6
                                                   --1



                                                                          50 mm



                                            --3


                         --6                Cut and Join Location


                                                                                  --4




     mm          in.
     50         1.97

1.    Cut and join the panels at the location as shown above.
                                           BODY PANEL REPLACEMENT                                               RE-47
INSTALLATION


                                                   --1
                                                 --3
                                 -- 12
                                            --2                   --2

                                                                  --2


                                                                        --3
                                                                         --4
                     --8
                                                   --1

                                                                              Butt Weld
                                           --3
                               Assembly Mark




                        --6




                                                                                     --4




1.   Determine the position of the new parts by the assem-   2.   Before welding the new parts, temporarily install the
     bly marks of the inner and outer panels.                     quarter panel and check the fit.
