Image preview - the first page of the document
rearfloo


>> Download rearfloo documenatation <<

Text preview - extract from the document
RE-64                                               BODY PANEL REPLACEMENT

     REAR FLOOR PAN (CUT)
REMOVAL (With the body lower back panel, rear floor
        No.6 crossmember removed.)



                                           Cut and Join Location




                                                                     -- 25              1,120 mm



             --3                                                                                                           --3




                                                                    -- 25




                              -- 11                                                                           -- 11
                                                     --8           --8          --8       --8


                           Rear Floor Side Panel


                                              --7



                               --3

                                                                         --10




                                 -- 10
                                                      --4


                                                                                                        --3

     mm             in.
     1,120         44.09

1.     Cut and join the parts at the location as shown above.            2.     Replace the rear floor side panel at the same time.
                                              BODY PANEL REPLACEMENT                                                       RE-65
INSTALLATION




                                                  -- 25           -- 14




                                                                                                                     --3
        --3




                                                                 -- 25




                 -- 11                  --8                --8      --8             --8                -- 11




                                                                                               --7



                                                                                --3
                                                                                                                           -- 10




                        1,110 mm
                                   Cut Location                                     -- 10
                                                                                                               --4




                                     --3




          --2                --2
                       --2

     mm          in.
     1,110      43.70                                                         --3


1.     Cut the new parts at the location as shown above.             HINT:     Be sure the portion to be welded are align and not
2.     Plug weld the overlapping portion of the new parts.           loose.
                                                                     3.   Coat the overlapping opening poriton from the both
                                                                          sides with body sealer.
