RE-28                                        BODY PANEL REPLACEMENT

     ROCKER OUTER PANEL (CUT)
REMOVAL




                                                                                       --1
                                                                                --9
                                                      20 mm




                                                                                             --1




                                                                                      --1
                                                                            --9

                                       Cut and Join Location




                                                      [Cut and Join Location]




     mm          in.
      20        0.79

1.    Cut and join the parts at the location as shown above.
                                            BODY PANEL REPLACEMENT                     RE-29
INSTALLATION




                                                               --9         --1




                                                                                 --1




                                                                     --1
                                                              --9

                                             Butt Weld




1.   Temporarily install the new parts and check the fit of
     the front door.
