Image preview - the first page of the document
roofpane


>> Download roofpane documenatation <<

Text preview - extract from the document
RE-74                    BODY PANEL REPLACEMENT

 ROOF PANEL (ASSY): Nomal Roof
REMOVAL




          --9             -- 10
                                        --9




                        -- 18           --2
                --2




                                -- 37




                -- 24                         4 Door:   -- 40
                                              5 Door:   -- 37
                                                BODY PANEL REPLACEMENT                       RE-75
INSTALLATION




              --9                            -- 10
                                                               --9




                                       -- 18
                       --2                                     --2




       [Foamed Material Apprication Areas]




                                                       -- 49
                                                                               Body Sealer



                        A-A




                             A
     --5

                A
                                                 A

                                                                     4 Door:   -- 52
                                                                     5 Door:   -- 49
                     -- 19        A

                                      --5




1.    Before temporarily installling the new parts, apply
      body sealer to the windshield header panel, roof panel
      reinforcement and back window frame.
HINT:
1) Apply just enough sealer for the new parts to make
    contact.
2)    For other sealing points, refer to Section AR.
