Image preview - the first page of the document
roofside


>> Download roofside documenatation <<

Text preview - extract from the document
RE-56                                        BODY PANEL REPLACEMENT

     ROOF SIDE OUTER PANEL (CUT)
REMOVAL (With the quarter panel rear lower extension
        removed.)




                                     Cut and Join Location




                                                                               50 mm
                                     -- 12
                                                                                 --3




                                                                                   --4




                                    --6


                                                                         --6



                                                                   --1




                                  --1


                                                                         --3

                                                             --7


     mm          in.
      50        1.97

1.    Cut and join the parts at the location as shown above.
                         BODY PANEL REPLACEMENT                    RE-57
INSTALLATION




                            Butt Weld




                 -- 16
                                                            --4




                                                             --6




                --8


                                                      --8



                                                --1




               --1


                                                      --4

                                        -- 10
