Image preview - the first page of the document
howtouse


>> Download howtouse documenatation <<

Text preview - extract from the document
IN-2                                 INTRODUCTION - How to Use This Manual
HOW TO USE THIS MANUAL
Each repair method description provided in Section RE of this manual comprises two pages, divided into 2 blocks (REMOVAL
AND INSTALLATION) and includes illustrations to facilitate body repair.



                      A
                                                                                                              B




                        C
                                                                                                              G



                                                                                                               H




                        D


A :     REPLACEMENT PARTS AND METHOD

                QUARTER PANEL (CUT)
                                                   Replacement method
                                                      (ASSY) . . . . .    Assembly replacement
                                                      (CUT) . . . . . .   Major cutting (less than 1 / 2 of parts used)
                                                      (CUT-H) . . . .     Half cutting (about 1 / 2 of parts used)
                                                      (CUT-P) . . . .     Partial cutting (most of parts used)
                                                   Replacement Parts

B :     PARTS LOCATION

C :     REMOVAL DIAGRAM
        Describes in detail removal of the damaged parts involving repair by cutting.

D :     REMOVAL GUIDE
        Provides additional information to more efficiently help you perform the removal.
                                    INTRODUCTION - How to Use This Manual                                            IN-3




                       G




                                                                                                 E
                       H




                                                                                                F




E :   INSTALLATION DIAGRAM
      Describes in detail installation of the new parts involving repair by welding and/or cutting, but excluding painting.

F :   INSTALLATION GUIDE
      Provides additional information to more efficiently help you perform the installation.

G :   SYMBOLS
      See page IN-4.

H :   ILLUSTRATION OF WELD POINTS
      Weld method and panel position symbols.
      See page IN-5.
