MOON ROOF
FROM POWER SOURCE SYSTEM (SEE PAGE 52)
1
30A 25A 10A
POWER DOOR GAUGE
2
5 1
POWER
RELAY
3 2
7 1F 8 1J 5 1G 1 1D
L- W
B- R
7 3D
W- B
L
1 IG2
19 3D
B- R
L- W
M2
MOON ROOF CONTROL SW
AND RELAY 4 10 24 A 15 A 7
IG E P/W B IG
SLIDE OPEN
TILT UP
DCTY PCTY
6 I13 A 4
G LS#2 LS# 1 MTR+ MTR-
INTEGRATION
2 7 3 5 1 RELAY
7 1S 2 1V
R- G
G- W
W- B
R- L
G
R
10 3A
6 5 1 2
3 3B
NO. 2
NO. 1
R- G
M
R- G
4 3 M3
MOON ROOF MOTOR
AND LIMIT SW
W- B
W- B
3 II2
R- G
W- B
I9
DOOR COURTESY
DOOR COURTESY
1 1
SW FRONT RH
SW FRONT LH
W- B
W- B
D16
D17
BL IJ
2001 SIENNA (EWD420U)
158
SYSTEM OUTLINE
Current is applied at all times through the POWER fuse to TERMINAL 5 of the power relay. With the ignition SW turned on,
the current flows through the GAUGE fuse to TERMINAL 7 of the integration relay to TERMINAL (A) 24 to TERMINAL 1 of
the power relay to TERMINAL 2 to GROUND, as a result, the power relay is activated and the current to TERMINAL 5 of the
power relay flows from TERMINAL 3 to TERMINAL 4 of the moon roof control SW and relay.
1. SLIDE OPEN OPERATION
Only when the slide open switch is valid and actuated, the moon roof motor will operate continually towards the open
direction of the roof panel.
Releasing and depressing again the open switch, or depressing another operation switch shall cancel this express open
function. The relay shall operate the moon roof motor continually for only approx. 20 seconds per actuation.
2. SLIDE CLOSE OPERATION
Only when the tilt up switch is valid and actuated, the moon roof motor will operate towards the close direction of the roof
panel.
When the moon roof reaches half position, the limit switch no. 1 is turned from on to off. Thereby signaling the moon roof
control relay to stop the motor. The motor can not continue operation until the close switch is released and depressed again.
3. TILT UP OPERATION
Only when the tilt up switch is valid and actuated, the moon roof motor will operate towards the closed direction of the roof
panel.
4. TILT DOWN OPERATION
Only when the slide open switch is valid and actuated, the moon roof motor will operate towards the open direction of the
roof panel.
5. KEY OFF MOON ROOF OPERATION
With the ignition SW turned from on to off, the integration relay operates and the current flows from the DOOR fuse to
TERMINAL (A) 15 of the integration relay to TERMINAL (A) 24 to TERMINAL 1 of the power relay to TERMINAL 2 to
GROUND for about 43 seconds. In the same way as normal operation, the current flows from the POWER fuse to
TERMINAL 5 of the power relay to TERMINAL 3 to TERMINAL 4 of the moon roof control SW and relay. As a result, this
relay is still activated for about 43 seconds after the ignition SW is turned off, allowing the open/close operation of the moon
roof. Also, by opening the front door (Door open detection SW on) within about 43 seconds after turning the ignition SW to
off, a signal is input to TERMINAL 6 or 4 of the integration relay. As a result, the relay turns off and open/close movement of
the moon roof stops.
SERVICE HINTS
POWER RELAY
5-3 : Closed with the ignition SW at ON position or key off moon roof operation
M2 MOON ROOF CONTROL SW AND RELAY
2-GROUND : Always continuity
4-GROUND : Approx. 12 volts with the ignition SW at ON position or key off moon roof operation
: PARTS LOCATION
Code See Page Code See Page Code See Page
D16 36 I13 A 35 M3 37
D17 36 M2 37
,,, : JUNCTION BLOCK AND WIRE HARNESS CONNECTOR
,,,
,,,
Code See Page Junction Block and Wire Harness (Connector Location)
1D 22 Cowl Wire and Driver Side J/B No.1 (Lower Finish Panel)
1F 22 Roof Wire and Driver Side J/B No.1 (Lower Finish Panel)
1G 22 Instrument Panel Wire and Driver Side J/B No.1 (Lower Finish Panel)
1J 22 Cowl Wire and Driver Side J/B No.1 (Lower Finish Panel)
1S 22 Floor Wire and Driver Side J/B No.1 (Lower Finish Panel)
1V 22 Cowl Wire and Driver Side J/B No.1 (Lower Finish Panel)
3A
3B 26 Cowl Wire and J/B No.3 (
(Behind the Combination Meter)
)
3D
2001 SIENNA (EWD420U)
159
MOON ROOF
: CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS
Code See Page Joining Wire Harness and Wire Harness (Connector Location)
IG2 42 Instrument Panel Wire and Cowl Wire (Behind the Combination Meter)
II2 44 Floor No.2 Wire and Cowl Wire (Right Kick Panel)
: GROUND POINTS
Code See Page Ground Points Location
IJ 42 Right Cowl Side Panel
BL 46 Left Side of the Roof Side Panel
: SPLICE POINTS
Code See Page Wire Harness with Splice Points Code See Page Wire Harness with Splice Points
I9 44 Cowl Wire
