Image preview - the first page of the document
>> Download 053amgdo documenatation <<
Text preview - extract from the document
Accessory Meter and Garage Door Opener
From Power Source System (See Page 58)
10A 10A 10A
DOME ECU- IG PANEL
3 2C 10 1R 12 1L
G
R
Connector
27 Junction
27 1C
J20
J20
Junction Connector
47
43 44 V- W
B- R
G
V- W
6 1R 45 85 75
2 IG1
11 ID2 4 ID2
R
V- W
V- W
V- W
V- W
V- W
G
1 5 8 3
A29
Accessory Meter
8 17 3
4 6 2 7 9
SPD SPD SPD
W- R
W- B
W
R
V
C9 E5 R12
Clearance Engine Radio and Player
Sonar ECU Control with Display
Module
1 1R 12 ID2 9 BA1
W- R
16 1L
V
5
SPD
M5
Moon Roof
Control ECU
W- B
V- W
W- R
W
R
IE
270
2005 SIENNA (EWD613U)
From Power Source System (See Page 58) * 1 : w/ VSC
* 2 : w/o VSC
10A 7. 5A
ECU- B GAUGE2
8 2C
W- L 25 1H
24 1C
B- R
7 1L
W- L
Connector
54
Junction
J19
34
W- L
C10
12 32 Combination Meter
Speedometer
35 30 36 26 23 33 34
GR- R
W- R
V- W
W- B
W
R
J 7(A), J 8(B)
4 B
Connector
Junction
8 ID2 9 ID2
Connector
16 A A 49
Junction
J20
Junction
J16
Connector
GR
A 50
12 A (* 1)
BR
17 B (* 2)
SP1
W- R
W- B
S 3(A), (B)
Skid Control ECU
with Actuator
V- W
W- R
W
R
IF IG
271
2005 SIENNA (EWD613U)
Accessory Meter and Garage Door Opener
Service Hints
A29 Accessory Meter
1-Ground : Always approx. 12 volts
5-Ground : Approx. 12 volts with the ignition SW at ON position
4-Ground : Always continuity
: Parts Location
Code See Page Code See Page Code See Page
A29 38 J8 B 36 R12 37
C9 35 J16 36 A 33
S3
C10 35 J19 36 B 33
E5 35 J20 36
J7 A 36 M5 39
: Junction Block and Wire Harness Connector
Code See Page Junction Block and Wire Harness (Connector Location)
1C 27 Engine Room Main Wire and Driver Side J/B (Lower Finish Panel)
1H 26
Instrument Panel Wire and Driver Side J/B (Lower Finish Panel)
1L 27
1R 27 Roof Wire and Driver Side J/B (Lower Finish Panel)
2C 22 Engine Room Main Wire and Engine Room J/B (Engine Compartment Left)
: Connector Joining Wire Harness and Wire Harness
Code See Page Joining Wire Harness and Wire Harness (Connector Location)
ID2 46 Roof Wire and Instrument Panel Wire (Near the Driver Side J/B)
IG1 46 Instrument Panel No.2 Wire and Instrument Panel Wire (Instrument Panel Brace RH)
BA1 50 Roof No.3 Wire and Roof Wire (Front Side of the Roof)
: Ground Points
Code See Page Ground Points Location
IE 46 Left Kick Panel
IF 46 Instrument Panel Brace LH
IG 46 Right Kick Panel
272
2005 SIENNA (EWD613U)
Memo
273
