Image preview - the first page of the document
>> Download 052rcm documenatation <<
Text preview - extract from the document
Remote Control Mirror
From Power Source System (See Page 58)
7. 5A
ECU
ACC
8 1L
P
Connector
88
Junction
J18
98
P
R17
Remote Control Mirror SW 8
B
Operation
SW
Right/
Down
Down
Right
Left/
Left
Up
Up
MH MV
Select SW
HL HR VL VR M+ E
5 2 4 3 6 7
W- B
P- L
Connector
112 32
Junction
J20
113 114 42
LG- R
LG- B
W- B
Y- B
P- L
P- L
GR
13 IA1 14 IA1 8 IM2 9 IM2 5 IM2 6 IA1
LG- R
LG- B
Y- B
P- L
P- L
GR
8 6 8 6
MH MV MH MV
M M M M
M+ M+
M3 7 M4 7
Remote Control Remote Control P- L
Mirror LH Mirror RH
P- L
W- B
IG
268
2005 SIENNA (EWD613U)
Service Hints
R17 Remote Control Mirror SW
8-Ground : Approx. 12 volts with the ignition SW at ACC or ON position
6-7 : Continuity with the operation SW at UP or LEFT position
8-6 : Continuity with the operation SW at DOWN or RIGHT position
: Parts Location
Code See Page Code See Page Code See Page
J18 36 M3 39 R17 37
J20 36 M4 39
: Junction Block and Wire Harness Connector
Code See Page Junction Block and Wire Harness (Connector Location)
1L 27 Instrument Panel Wire and Driver Side J/B (Lower Finish Panel)
: Connector Joining Wire Harness and Wire Harness
Code See Page Joining Wire Harness and Wire Harness (Connector Location)
IA1 46 Front Door LH Wire and Instrument Panel Wire (Left Kick Panel)
IM2 48 Front Door RH Wire and Instrument Panel Wire (Right Kick Panel)
: Ground Points
Code See Page Ground Points Location
IG 46 Right Kick Panel
269
2005 SIENNA (EWD613U)
