Image preview - the first page of the document
bodydime


>> Download bodydime documenatation <<

Text preview - extract from the document
                                                     BODY DIMENSIONS                                                                   DI-3


BODY DIMENSION DRAWINGS
ENGINE COMPARTMENT

 (Three-Dimensional Distance)




           Height from Imaginary Standard Line              Vehicle Dimensions




                                                                                                                                 mm (in.)
Symbol                        Name                    Hole dia.       Symbol                        Name                      Hole dia.
 A, a    Front fender installation nut               6 (0.24) nut       I      Hood lock support installation nut            6 (0.24) nut
 B, b    Front spring support hole-inner             12.5 (0.492)      J, j    Front bumper reinforcement installation nut   10 (0.39) nut
 C, c    Hood hinge installation nut-rear            8 (0.31) nut      K, k    Fender apron plate standard hole               10 (0.39)
                                                          12
