DI-6                                                    BODY DIMENSIONS

BODY OPENING AREAS (Rear View)


 (Three-Dimensional Distance)




                                                                                      Vehicle Dimensions Left $ Right




                                                                                                                              mm (in.)
Symbol                        Name                       Hole dia.     Symbol                        Name                  Hole dia.
 A, a    Back door hinge installation hole-outer         12 (0.47)      E, e    Back door scuff plate installation hole   8.5 (0.335)
 B, b    Back door damper stay installation nut-lower   8 (0.31) nut    F, f    Back door lock striker installation nut   8 (0.31) nut
 C, c    Quarter Panel standard hole                     13 (0.51)      G, g    Rear shock absorber installation hole      24 (0.94)
 D, d    Quarter trim installation hole                 8.5 (0.335)     H, h    Center body pillar assembly mark              --
