BODY DIMENSIONS DI-11
FRONT FRAME
4WD
(Three-Dimensional Distance)
Front
Vehicle Dimensions Left $ Right
Imaginary
Standard
Line
mm (in.)
Symbol Name Hole dia. Symbol Name Hole dia.
A, a Front frame standard hole 13 (0.51) D, d Front frame standard hole 13 (0.51)
B, b Front frame standard hole 13 (0.51) E, e Lower arm installation hole 15 (0.59)
C, c Front frame standard hole 13 (0.51) -- -- --
