Image preview - the first page of the document



>> Download front0 documenatation <<

Text preview - extract from the document

DI-12                                   BODY DIMENSIONS

FRONT FRAME
2WD




                                     (Two-Dimensional Distance)


                                                     Front




                                                                                                Imaginary
                                                                                                Standard
                                                                                                Line




                                                                                                              mm (in.)
Symbol                      Name         Hole dia.      Symbol                       Name                   Hole dia.
 A, a    Front frame standard hole       13 (0.51)       D, d     Front frame standard hole                 13 (0.51)
 B, b    Front frame standard hole       13 (0.51)       E, e     Lower arm installation hole               15 (0.59)
 C, c    Front frame standard hole       13 (0.51)           --                        --                      --
