Image preview - the first page of the document



>> Download no1lower documenatation <<

Text preview - extract from the document

BP-42                                   BODY PANEL REPLACEMENT


 NO.1 LOWER OUTER RAIL (ASSY)
 REPLACEMENT
 With the center body pillar and rocker outer panel removed.


                                                                 F14993-A

 REMOVAL




                                                                  F14993

 POINT
 1   *1 [A] is reuse.
 PART NAME
 [A] Quarter Panel
 130mm (5.12in.)
BODY PANEL REPLACEMENT   BP-43




                         F14994
BP-44                                     BODY PANEL REPLACEMENT


 INSTALLATION
 S Temporarily install the new parts and measure each part of the new parts in accordance with the body dimension
   diagram. (See the body dimension diagram)
 S Inspect the fitting of the related parts around the new parts before welding. This affects the appearance of the
   finish.
 S After welding, apply the polyurethane foam to the corresponding parts.
 S After welding, apply body sealer and under-coating to the corresponding parts.
 S After applying the top coat layer, apply anti-rust agent to the inside of the necked section structural weld spots.




                                                                                                                     F14995

 POINT
 1   Inspect the fitting of the slide door, etc., before welding, since this affects the appearance of the finish.


 25mm (0.98in.)
                    BODY PANEL REPLACEMENT   BP-45




                                             F14996

PART NAME
[A] Quarter Panel
