Image preview - the first page of the document



>> Download backd documenatation <<

Text preview - extract from the document

                                     BODY PANEL REPLACEMENT   BP-59


BACK DOOR OPENING SIDE
REINFORCEMENT (CUT)
REPLACEMENT
With the back door opening trough removed.

                                                              F15009-A

REMOVAL




                                                               F15009




150mm (5.91in.)
BP-60                                     BODY PANEL REPLACEMENT


 INSTALLATION
 S Temporarily install the new parts and measure each part of the new parts in accordance with the body dimension
   diagram. (See the body dimension diagram)
 S Inspect the fitting of the related parts around the new parts before welding. This affects the appearance of the
   finish.
 S After welding, apply the polyurethane foam to the corresponding parts.
 S After welding, apply body sealer and under-coating to the corresponding parts.
 S After applying the top coat layer, apply anti-rust agent to the inside of the necked section structural weld spots.




                                                                                                                  F15010
