                                     BODY PANEL REPLACEMENT                                BP-61


BACK DOOR OPENING LOWER GUSSET
(ASSY)
REPLACEMENT
With the back door opening side reinforcement removed.

                                                                                           F15011-A

REMOVAL




                                                                                            F15011

POINT
1   Remove the [A] and [B] at the same time.
PART NAME
[A] Rear Bumper Arm Support Reinforce          [B]   Body Lower Back Reinforcement Plate
BP-62                                     BODY PANEL REPLACEMENT


 INSTALLATION
 S Temporarily install the new parts and measure each part of the new parts in accordance with the body dimension
   diagram. (See the body dimension diagram)
 S Inspect the fitting of the related parts around the new parts before welding. This affects the appearance of the
   finish.
 S After welding, apply the polyurethane foam to the corresponding parts.
 S After welding, apply body sealer and under-coating to the corresponding parts.
 S After applying the top coat layer, apply anti-rust agent to the inside of the necked section structural weld spots.




                                                                                                                  F15012

 PART NAME
 [A] Rear Bumper Arm Support Reinforce            [B]   Body Lower Back Reinforcement Plate
