Image preview - the first page of the document



>> Download bodyl documenatation <<

Text preview - extract from the document

                                       BODY PANEL REPLACEMENT   BP-67


BODY LOWER BACK OUTER PANEL (ASSY)
REPLACEMENT



                                                                F15017-A

REMOVAL




                                                                 F15017

POINT
1   Remove the [A] at the same time.
PART NAME
[A] Body Lower Back Inner Panel
60mm (2.36in.)
BP-68                                     BODY PANEL REPLACEMENT


 INSTALLATION
 S Temporarily install the new parts and measure each part of the new parts in accordance with the body dimension
   diagram. (See the body dimension diagram)
 S Inspect the fitting of the related parts around the new parts before welding. This affects the appearance of the
   finish.
 S After welding, apply the polyurethane foam to the corresponding parts.
 S After welding, apply body sealer and under-coating to the corresponding parts.
 S After applying the top coat layer, apply anti-rust agent to the inside of the necked section structural weld spots.




                                                                                                                    F15018

 POINT
 1   Inspect the fitting of the back door, etc., before welding, since this affects the appearance of the finish.
 PART NAME
 [A] Body Lower Back Inner Panel    [B] Back Door Lock Striker Reinforcement
 [C] Door Lock Striker Retainer  [D] Rear Bumper Upper Center Retainer
 [E] Lower Back Trim Retainer
                                        BODY PANEL REPLACEMENT   BP-69




                                                                 F15019

POINT
1   *1: The value is reference value.
PART NAME
[D] Rear Bumper Upper Center Retainer
60mm (2.36in.)
