Image preview - the first page of the document
bodylowe


>> Download bodylowe documenatation <<

Text preview - extract from the document
                                       BODY PANEL REPLACEMENT   BP-63


BODY LOWER BACK PANEL
REINFORCEMENT (ASSY)
REPLACEMENT
With the back door opening lower gusset removed.

                                                                F15013-A

REMOVAL




                                                                 F15013

POINT
1   Remove the [A] at the same time.
2   *1: RH Only
PART NAME
[A] Lower Back Side Panel
BP-64                                     BODY PANEL REPLACEMENT


 INSTALLATION
 S Temporarily install the new parts and measure each part of the new parts in accordance with the body dimension
   diagram. (See the body dimension diagram)
 S Inspect the fitting of the related parts around the new parts before welding. This affects the appearance of the
   finish.
 S After welding, apply the polyurethane foam to the corresponding parts.
 S After welding, apply body sealer and under-coating to the corresponding parts.
 S After applying the top coat layer, apply anti-rust agent to the inside of the necked section structural weld spots.




                                                                                                                  F15014

 POINT
 1   *1: RH Only
 PART NAME
 [A] Lower Back Side Panel
