BP-28                          BODY PANEL REPLACEMENT


 CENTER BODY PILLAR (CUT)
 REPLACEMENT



                                                                           F14979-A

 REMOVAL




                                                                            F14979




 40mm (1.57in.)   50mm (1.97in.)     200mm (7.87in.)    510mm (20.08in.)
                                       BODY PANEL REPLACEMENT                             BP-29




                                                                                          F14980

POINT
1   Separate the [B] and [C] at the welded part, at then remove the center body pillar.
PART NAME
[A] Center Body Inner Pillar    [B] Center Body Pillar Center Reinforcement
[C] Center Body Pillar Outer Reinforcement
BP-30                                     BODY PANEL REPLACEMENT


 INSTALLATION
 S Temporarily install the new parts and measure each part of the new parts in accordance with the body dimension
   diagram. (See the body dimension diagram)
 S Inspect the fitting of the related parts around the new parts before welding. This affects the appearance of the
   finish.
 S After welding, apply the polyurethane foam to the corresponding parts.
 S After welding, apply body sealer and under-coating to the corresponding parts.
 S After applying the top coat layer, apply anti-rust agent to the inside of the necked section structural weld spots.




                                                                                                                  F14981

 POINT
 1   Take care not to damage the internal reinforcement.
 PART NAME
 [B] Center Body Pillar Center Reinforcement      [C] Center Body Pillar Outer Reinforcement
 [D] Rocker Outer Reinforce
 40mm (1.57in.)         255mm (10.04in.)
                                          BODY PANEL REPLACEMENT                                                   BP-31




                                                                                                                    F14982

POINT
1   Inspect the fitting of the front door and slide door, etc., before welding, since this affects the appearance of the
    finish.
2   After welding the reinforcement to the vehicle side, install the outer panel.
PART NAME
[A] Center Body Inner Pillar        [C]   Center Body Pillar Outer Reinforcement



15mm (0.59in.)
