Image preview - the first page of the document
fitstand


>> Download fitstand documenatation <<

Text preview - extract from the document
                    BODY PANEL REPLACEMENT                      BP-91


                      FIT STANDARDS




                                                                F15050

4.0mm (0.157in.)    5.0mm (0.197in.)         5.7mm (0.224in.)
6.0mm (0.236in.)    6.5mm (0.256in.)         7.0mm (0.276in.)
10.5mm (0.413in.)
BP-92               BODY PANEL REPLACEMENT




                                                                F15051

 5.0mm (0.197in.)   5.5mm (0.217in.)         5.6mm (0.220in.)
 6.3mm (0.248in.)   7.0mm (0.276in.)         8.0mm (0.315in.)
 8.1mm (0.319in.)
