                                       BODY PANEL REPLACEMENT       BP-17


FRONT APRON TO COWL SIDE MEMBER
(ASSY)
REPLACEMENT
With the front body pillar lower gusset removed.

                                                                    F14967-A

REMOVAL




                                                                     F14967

POINT
1   Remove the [A], [B] and [C] at the same time.
2   *1: RH Only
PART NAME
[A] Front Apron To Cowl Side Member        [B] Front Panel Gusset
[C] Front Fender Apron Rear Extension
BP-18                                     BODY PANEL REPLACEMENT


 INSTALLATION
 S Temporarily install the new parts and measure each part of the new parts in accordance with the body dimension
   diagram. (See the body dimension diagram)
 S Inspect the fitting of the related parts around the new parts before welding. This affects the appearance of the
   finish.
 S After welding, apply the polyurethane foam to the corresponding parts.
 S After welding, apply body sealer and under-coating to the corresponding parts.
 S After applying the top coat layer, apply anti-rust agent to the inside of the necked section structural weld spots.




                                                                                                                  F14968

 POINT
 1   Inspect the fitting of the front fender and hood, etc., before welding, since this affects the appearance of the
     finish.
 2   *1: RH Only
 PART NAME
 [A] Front Apron To Cowl Side Member           [B]   Front Panel Gusset
 [C] Front Fender Apron Rear Extension


 15mm (0.59in.)
                                        BODY PANEL REPLACEMENT   BP-19




                                                                 F14962

POINT
1   *1: The value is reference value.


213mm (8.39in.)
