Image preview - the first page of the document



>> Download quarterw documenatation <<

Text preview - extract from the document

                                       BODY PANEL REPLACEMENT               BP-53


QUARTER WHEEL HOUSING OUTER PANEL
(ASSY)
REPLACEMENT
With the quarter panel and quarter lock pillar extension removed.

                                                                            F15003-A

REMOVAL




                                                                             F15003

POINT
1   After removing the [A], remove the quarter wheel housing outer panel.
PART NAME
[A] Roof Side Inner To Wheel Housing Brace
BP-54                                  BODY PANEL REPLACEMENT




                                                                             F15004

 POINT
 1   After removing the [A], remove the quarter wheel housing outer panel.
 PART NAME
 [A] Roof Side Inner To Wheel Housing Brace
                                         BODY PANEL REPLACEMENT                                                 BP-55


INSTALLATION
S Temporarily install the new parts and measure each part of the new parts in accordance with the body dimension
  diagram. (See the body dimension diagram)
S Inspect the fitting of the related parts around the new parts before welding. This affects the appearance of the
  finish.
S After welding, apply the polyurethane foam to the corresponding parts.
S After welding, apply body sealer and under-coating to the corresponding parts.
S After applying the top coat layer, apply anti-rust agent to the inside of the necked section structural weld spots.




                                                                                                                 F15005

POINT
1   Determine the position of the new parts by assembly marks of the inner and outer panels.
PART NAME
[A] Roof Side Inner To Wheel Housing Brace
20mm (0.79in.)
BP-56                                  BODY PANEL REPLACEMENT




                                                                                                F15006

 POINT
 1   Determine the position of the new parts by assembly marks of the inner and outer panels.
 PART NAME
 [A] Roof Side Inner To Wheel Housing Brace
 20mm (0.79in.)
