Image preview - the first page of the document



>> Download quarterp documenatation <<

Text preview - extract from the document

BP-46                                   BODY PANEL REPLACEMENT


 QUARTER PANEL (CUT)
 REPLACEMENT



                                                                                   F14997-A

 REMOVAL




                                                                                    F14997

 POINT
 1   Remove the [A] at the same time.
 PART NAME
 [A] Quarter Lock Pillar Reinforcement
 30mm (1.18in.)          70mm (2.76in.)       140mm (5.51in.)    160mm (6.30in.)
BODY PANEL REPLACEMENT   BP-47




                         F14998
BP-48                                     BODY PANEL REPLACEMENT


 INSTALLATION
 S Temporarily install the new parts and measure each part of the new parts in accordance with the body dimension
   diagram. (See the body dimension diagram)
 S Inspect the fitting of the related parts around the new parts before welding. This affects the appearance of the
   finish.
 S After welding, apply the polyurethane foam to the corresponding parts.
 S After welding, apply body sealer and under-coating to the corresponding parts.
 S After applying the top coat layer, apply anti-rust agent to the inside of the necked section structural weld spots.




                                                                                                                  F15055

 POINT
 1   Before temporarily installing the new parts, apply sealer to the wheel arch.
     HINT:
     1) Apply body sealer about 5mm (0.20in.) from the flange, avoiding any oozing.
     2) Apply sealer evenly, about 3 - 4mm (0.12 - 0.16in.) in diameter.
 PART NAME
 [A] Quarter Lock Pillar Reinforcement
                                          BODY PANEL REPLACEMENT                                                    BP-49




                                                                                                                     F14999

POINT
1   Inspect the fitting of the slide door, back door and rear combination light, etc., before welding, since this affects
    the appearance of the finish.
2   Use waterproof rivets for the [B] installation.
PART NAME
[A] Quarter Lock Pillar Reinforcement          [B]   Fuel Filler Opening Lid      [C]   Quarter Panel Reinforcement
[D] Waterproof Rivets
BP-50   BODY PANEL REPLACEMENT




                                 F15000
