Image preview - the first page of the document



>> Download rearf documenatation <<

Text preview - extract from the document

BP-74                                   BODY PANEL REPLACEMENT


 REAR FLOOR SIDE REAR MEMBER (CUT)
 REPLACEMENT
 With the body lower back panel reinforcement, quarter panel upper rear exten-
 sion and rear floor pan removed.

                                                                                 F15024-A

 REMOVAL




                                                                                  F15024

 POINT
 1   Take care not to damage the internal reinforcement.
 2   Remove the [A] at the same time.
 PART NAME
 [A] Rear Floor Side Member Cover
 50mm (1.97in.)         100mm (3.94in.)
                                    BODY PANEL REPLACEMENT            BP-75




                                                                      F15025

POINT
1   Take care not to damage the internal reinforcement.
2   Remove the [A] at the same time.
PART NAME
[A] Rear Floor Side Member Cover       [D] Exhaust Pipe No.6 Hanger
50mm (1.97in.)         100mm (3.94in.)
BP-76                                     BODY PANEL REPLACEMENT


 INSTALLATION
 S Temporarily install the new parts and measure each part of the new parts in accordance with the body dimension
   diagram. (See the body dimension diagram)
 S Inspect the fitting of the related parts around the new parts before welding. This affects the appearance of the
   finish.
 S After welding, apply the polyurethane foam to the corresponding parts.
 S After welding, apply body sealer and under-coating to the corresponding parts.
 S After applying the top coat layer, apply anti-rust agent to the inside of the necked section structural weld spots.




                                                                                                                  F15026

 PART NAME
 [A] Rear Floor Side Member Cover           [C]   Rear Floor Side Rear Member



 100mm (3.94in.)          245mm (9.65in.)
                                   BODY PANEL REPLACEMENT                  BP-77




                                                                           F15027

PART NAME
[A] Rear Floor Side Member Cover    [B]   Rear Side Member Reinforcement



15mm (0.59in.)
BP-78                               BODY PANEL REPLACEMENT




                                                                         F15028

 PART NAME
 [A] Rear Floor Side Member Cover       [D]   Exhaust Pipe No.6 Hanger
 [C] Rear Floor Side Rear Member

 100mm (3.94in.)      245mm (9.65in.)
                                   BODY PANEL REPLACEMENT                  BP-79




                                                                           F15029

PART NAME
[A] Rear Floor Side Member Cover    [B]   Rear Side Member Reinforcement
[D] Exhaust Pipe No.6 Hanger

15mm (0.59in.)
