Image preview - the first page of the document
>> Download rearf1 documenatation <<
Text preview - extract from the document
BP-82 BODY PANEL REPLACEMENT
REAR FLOOR NO.4 CROSSMEMBER (ASSY)
REPLACEMENT
With the rear floor pan and rear floor No.5 crossmember removed.
F15032-A
REMOVAL
F15032
BODY PANEL REPLACEMENT BP-83
INSTALLATION
S Temporarily install the new parts and measure each part of the new parts in accordance with the body dimension
diagram. (See the body dimension diagram)
S Inspect the fitting of the related parts around the new parts before welding. This affects the appearance of the
finish.
S After welding, apply the polyurethane foam to the corresponding parts.
S After welding, apply body sealer and under-coating to the corresponding parts.
S After applying the top coat layer, apply anti-rust agent to the inside of the necked section structural weld spots.
F15033
