Image preview - the first page of the document
rearfloo


>> Download rearfloo documenatation <<

Text preview - extract from the document
BP-70                                 BODY PANEL REPLACEMENT


 REAR FLOOR PAN (ASSY)
 REPLACEMENT
 With the body lower back outer panel removed.


                                                               F15020-A

 REMOVAL




                                                                F15020
                                   BODY PANEL REPLACEMENT   BP-71




                                                            F15021

POINT
1   [A] is reuse.
2   *1: Turn Over
PART NAME
[A] Rear Floor Side Member Rear Plate
BP-72                                     BODY PANEL REPLACEMENT


 INSTALLATION
 S Temporarily install the new parts and measure each part of the new parts in accordance with the body dimension
   diagram. (See the body dimension diagram)
 S Inspect the fitting of the related parts around the new parts before welding. This affects the appearance of the
   finish.
 S After welding, apply the polyurethane foam to the corresponding parts.
 S After welding, apply body sealer and under-coating to the corresponding parts.
 S After applying the top coat layer, apply anti-rust agent to the inside of the necked section structural weld spots.




                                                                                                                  F15022

 PART NAME
 [B] Spare Wheel Carrier Bracket   [C]         Rear Floor Panel No.1 Reinforcement
 [D] Rear Floor Pan No.2 Reinforcement          [E] Rear Floor Panel No.4 Reinforcement
 [F] Rear Seat Mounting Reinforcement
                                   BODY PANEL REPLACEMENT   BP-73




                                                            F15023

POINT
1   *1: Turn Over
PART NAME
[A] Rear Floor Side Member Rear Plate
