BP-84                         BODY PANEL REPLACEMENT


 ROOF PANEL (ASSY): w/o sun roof
 REPLACEMENT



                                                       F15034-A

 REMOVAL




                                                        F15034

 POINT
 1   *1: w/ Rear Display +2
     *2: w/ Roof Rack +3
                                         BODY PANEL REPLACEMENT                                                 BP-85


INSTALLATION
S Temporarily install the new parts and measure each part of the new parts in accordance with the body dimension
  diagram. (See the body dimension diagram)
S Inspect the fitting of the related parts around the new parts before welding. This affects the appearance of the
  finish.
S After welding, apply the polyurethane foam to the corresponding parts.
S After welding, apply body sealer and under-coating to the corresponding parts.
S After applying the top coat layer, apply anti-rust agent to the inside of the necked section structural weld spots.




                                                                                                                 F15035

POINT
1   Before temporarily installing the new parts, apply body sealer to the windshield header panel, roof panel rein-
    forcement and back window frame.
HINT:
1) Apply just enough sealer for the new parts to make contact.
2   *1: w/ Rear Display Only        *2: w/ Roof Rack Only
