Image preview - the first page of the document



>> Download Converter Installation Xtra Cab documenatation <<

Text preview - extract from the document

VII. CONVERTER BOX INSTALLATION (EXTRA CAB)
                         1. INSTALLATION OF NEW CONVERTER BOX
                              (a) Remove the left scuff plate by removing
                                  the four screws.




                              (b) Remove the jack cover.




                              (c) Remove the grommet on the rear cab
                                  wall.
                              (d) Loosen the jack and re-secure the jack
                                  by hand.
                              (e) Clean area shown with a prep-solvent.




                              (f)   Install the new converter box.
                                    (1) Remove the four screws holding the
                                         converter box to the bracket.
                                    (2) Rotate the converter box 180
