Image preview - the first page of the document
>> Download Converter Removal documenatation <<
Text preview - extract from the document
V. REMOVE EXISTING TRAILER TOWING WIRE HARNESS
CONVERTER (ALL VEHICLES)
1. INSPECT VEHICLE
(a) Inspect vehicle as outlined in Section IV
to ensure that vehicle is equipped with a
Toyota trailer towing wire harness
converter.
2. DISCONNECT THE BATTERY
(a) Record radio station presets.
(b) Disconnect the negative (-) battery cable.
3. REMOVE THE ORIGINAL CONVERTER AND
TRAILER HITCH WIRING HARNESS
(a) Unbolt the original flat four connector
from the trailer hitch.
(b) Remove the ground connection from
underneath the body on the left side.
(c) Remove any tie-wraps holding the
converter wiring harness to the vehicle.
4. REMOVE BOTH TAILLIGHT ASSEMBLIES
(a) Lower tail gate.
(b) Remove the four mounting screws from
both taillight assemblies.
(c) Carefully remove both taillight
assemblies.
(d) Disconnect the taillight wire harness at
the connector and set the assembly
aside.
(e) Disconnect the jumper connector
assembly from both taillight harnesses.
NOTE:
