Image preview - the first page of the document
>> Download Installation of Bed Harness documenatation <<
Text preview - extract from the document
VIII. INSTALLATION OF BED HARNESS
1. INSTALL THE BED WIRE HARNESS
(a) Working from the cab rearward route the
wire harness along the left frame rail.
(b) Install 2 tie-wraps near the forward left bed
mount in the area shown.
(c) Install a tie-wrap near the brake load-
regulating valve.
(d) Install a tie-wrap near the left rear shock as
shown.
(e) Mount the flat four connector to the tow
hitch.
(f) Attach the flat four harness to the hitch with
a tie-wrap.
(g) Route the flat four harnesses to the
converter box harness.
(h) Connect the flat four harnesses to the
converter box harness and secure to
vehicle frame near left rear bumper mount.
1. INSPECT FUSES
Inspect the following fuses and replace as
necessary:
