Image preview - the first page of the document
>> Download Vehicle Inspection documenatation <<
Text preview - extract from the document
IV. VEHICLE INSPECTION
1. VERIFY VEHICLE ELIGIBILITY
(a) Confirm that the VIN is within the SSC
VIN range.
(b) Inspect the driver s sid door pillar for an
e
SSC completion label.
(c) Assure that the vehicle is equipped with a
Toyota trailer towing wire harness
converter.
Old style 2. INSPECT TRAILER TOWING FLAT FOUR
CONNECTOR
flat four The involved converter can be identified by
connector using a mirror to inspect the underside of the
plastic trailer towing flat four connector
(mounted on the driver s si under the trailer
de,
towing hitch) for the Toyota logo as indicated in
the diagram.
Needs to be
replaced
NOTE:
New style The new Trailer Towing Harness Converter
flat four (no need to replace) flat four connector is
connector mounted to a metal bracket.
Metal NOTE:
Bracket Since a customer may elect to install
aftermarket trailer towing equipment,
inspect the vehicle to determine if it is
equipped with the involved Toyota trailer
OK towing wiring harness converter. Only
Do not vehicles equipped with the old style flat four
connector are subject to this SSC.
replace
(a) If the flat four connector has
TOYOTA imprinte on it, then
d
continue to Section V.
(b) If the flat four connector does not have
TOYOTA imprinte on it or if the the
d
TOYOTA is imprint d on the metal
e
bracket portion. Proceed to Section X.
SSC COMPLETION LABEL
INSTALLATION an file an
d
INSPECTION ONLY SSC cl im. a
