Image preview - the first page of the document



>> Download cem7350 documenatation <<

Text preview - extract from the document

                                                                                         CEM7350
Dual Enhancement Mode Field Effect Transistor (N and P Channel)


FEATURES

  100V, 2.6A, RDS(ON) = 190m @VGS = 10V.

  -100V, -2.0A, RDS(ON) = 320m @VGS = -10V.

  Super high dense cell design for extremely low RDS(ON).

  High power and current handing capability.
                                                                                    D1     D1        D2    D2
  Lead free product is acquired.                                                    8          7     6     5

  Surface mount Package.




                                            SO-8
                                                                                    1          2     3     4
                                                            1                       S1         G1    S2    G2




ABSOLUTE MAXIMUM RATINGS                             TA = 25 C unless otherwise noted
                     Parameter                              Symbol        N-Channel            P-Channel        Units
  Drain-Source Voltage                                           VDS         100                    -100         V
  Gate-Source Voltage                                            VGS
