Image preview - the first page of the document



>> Download cep35p10_ceb35p10_cef35p10 documenatation <<

Text preview - extract from the document

                                                CEP35P10/CEB35P10
                                                         CEF35P10
P-Channel Enhancement Mode Field Effect Transistor

FEATURES

  -100V, -32A, RDS(ON) =76m @VGS = -10V.
               RDS(ON) =92m @VGS = -4.5V.
  Super high dense cell design for extremely low RDS(ON).

  High power and current handing capability.                                                    D

  Lead free product is acquired.

  TO-220 & TO-263 package.

                                        D
                                                                             G
                                                  G
                              G                   D
                                 S                 S
                             CEB SERIES                CEP SERIES
                             TO-263(DD-PAK)            TO-220                                   S



ABSOLUTE MAXIMUM RATINGS                               Tc = 25 C unless otherwise noted
                     Parameter                              Symbol                    Limit                 Units
  Drain-Source Voltage                                           VDS                  -100                   V
  Gate-Source Voltage                                            VGS
