                                                                                                                                                                     BC337-16 / BC337-25
                                         BC337-16
                                         BC337-25



                             E                          TO-92
                                 B
                                     C




          NPN General Purpose Amplifier
          This device is designed for use as general purpose amplifiers
          and switches requiring collector currents to 500 mA. Sourced from
          Process 12. See TN3019A for characteristics.


          Absolute Maximum Ratings*                                           TA = 25
