Discrete POWER & Signal
Technologies
ST5771-1
C TO-92
BE
PNP Switching Transistor
This device is designed for high speed saturated switching
applications at currents to 100mA. Sourced from Process 65.
See PN4258 for characteristics.
Absolute Maximum Ratings* TA = 25
