Image preview - the first page of the document



>> Download kta1759 documenatation <<

Text preview - extract from the document

                                     SEMICONDUCTOR                                                                                     KTA1759
                                              TECHNICAL DATA                                              EPITAXIAL PLANAR PNP TRANSISTOR


  HIGH VOLTAGE APPLICATION.

  FEATURES
    High Breakdown Voltage.
                                                                                                                      A
                                                                                                                                                 C
                                                                                                                      H
                                                                                                                                                      G


                                                                                                                                                      DIM       MILLIMETERS




                                                                                                                                      B
                                                                                                                                       J

                                                                                                                                      E
                                                                                                                                                       A           4.70 MAX
                                                                                                                                                                        _
                                                                                                                                                                   2.50 + 0.20
  MAXIMUM RATING (Ta=25                   )                                                                                                            B
                                                                                                                                   D                   C           1.70 MAX
                                                                                                          D
           CHARACTERISTIC                     SYMBOL               RATING          UNIT                                                                D        0.45+0.15/-0.10
                                                                                                                          K
                                                                                                                                                       E           4.25 MAX
                                                                                                                  F       F                            F                _
                                                                                                                                                                   1.50 + 0.10
   Collector-Base Voltage                         VCBO                -400               V                                                             G            0.40 TYP
                                                                                                                                                       H           1.75 MAX
   Collector-Emitter Voltage                      VCEO                -400               V                                                             J            0.75 MIN
                                                                                                                                                       K         0.5+0.10/-0.05
   Emitter-Base Voltage                           VEBO                 -7                V                    1       2       3


   Collector Current                                IC                -100          mA
                                                                                                                                       1. BASE

                                                   PC                                                                                  2. COLLECTOR (HEAT SINK)
                                                                      500          mW
                                                                                                                                       3. EMITTER
   Collector Power Dissipation
                                                  PC*                  1                 W
   Junction Temperature                             Tj                150
