Image preview - the first page of the document



>> Download kta2017 documenatation <<

Text preview - extract from the document

                                    SEMICONDUCTOR                                                                                    KTA2017
                                             TECHNICAL DATA                                                   EPITAXIAL PLANAR PNP TRANSISTOR


  LOW NOISE AMPLIFIER APPLICATION.

  FEATURES
                                                                                                                                 E
    High Voltage : VCEO=-120V.                                                                                          M        B       M

    Excellent hFE Linearity                                                                                                                               DIM    MILLIMETERS
                                                                                                                                                           A            _
                                                                                                                                                                   2.00 + 0.20
                                                                                                                                                      D
        : hFE(0.1mA)/hFE(2mA)=0.95(Typ.).                                                                                  2                              B             _
                                                                                                                                                                   1.25 + 0.15




                                                                                                          A
                                                                                                                                                                        _




                                                                                                               J
                                                                                                                                                          C        0.90 + 0.10
    High hFE: hFE=200 700.                                                                                                               3




                                                                                                                   G
                                                                                                                           1
                                                                                                                                                          D      0.3+0.10/-0.05
    Low Noise : NF=1dB(Typ.), 10dB(Max.).                                                                                                                 E             _
                                                                                                                                                                   2.10 + 0.20
                                                                                                                                                          G           0.65
    Complementary to KTC4077.                                                                                                                             H      0.15+0.1/-0.06
                                                                                                                                                          J             1.30
                                                                                                                                                          K          0.00-0.10
                                                                                                                                                          L             0.70




                                                                                                              C
                                                                                                                                                  H




                                                                                                                   L
                                                                                                                                                          M               _
                                                                                                                                                                     0.42 + 0.10
                                                                                                                                                          N          0.10 MIN
                                                                                                                       N                     N
                                                                                                                               K
  MAXIMUM RATING (Ta=25                  )
          CHARACTERISTIC                     SYMBOL            RATING             UNIT
                                                                                                                       1. EMITTER
   Collector-Base Voltage                     VCBO                  -120                 V                             2. BASE
                                                                                                                       3. COLLECTOR
   Collector-Emitter Voltage                  VCEO                  -120                 V
   Emitter-Base Voltage                       VEBO                     -5                V
   Collector Current                           IC                   -100           mA
                                                                                                                                             USM
   Base Current                                IB                   -20            mA
   Collector Power Dissipation                 PC                   100            mW
   Junction Temperature                        Tj                   150
