Image preview - the first page of the document
>> Download ktc3553t documenatation <<
Text preview - extract from the document
SEMICONDUCTOR KTC3553T
TECHNICAL DATA EPITAXIAL PLANAR NPN TRANSISTOR
RELAY DRIVERS, LAMP DRIVERS,
MOTOR DRIVERS AND STROBES APPLICATION.
E
FEATURES K B
DIM MILLIMETERS
Adoption of MBIT Processes. A _
2.9 + 0.2
High Current Capacitance. B 1.6+0.2/-0.1
C _
0.70 + 0.05
2
Low Collector-to-Emitter Saturation Voltage.
G
3 _
D 0.4 + 0.1
D
A
E 2.8+0.2/-0.3
F
Ultrasmall-Sized Package permitting applied sets to be F _
1.9 + 0.2
1
G
made small and slim. G 0.95
H _
0.16 + 0.05
High Allowable Power Dissipation. I 0.00-0.10
J 0.25+0.25/-0.15
Complementary to KTA1553T. K 0.60
C
L 0.55
L
MAXIMUM RATING (Ta=25 ) H
I
J J
CHARACTERISTIC SYMBOL RATING UNIT
1. EMITTER
Collector-Base Voltage VCBO 60 V 2. BASE
3. COLLECTOR
Collector-Emitter Voltage VCEO 50 V
Emitter-Base Voltage VEBO 6 V
DC IC 5
Collector Current A TSM
Pulse ICP 7
Base Current IB 1.2 A
Collector Power Dissipation PC * 0.9 W Marking
Junction Temperature Tj 150 Lot No.
Storage Temperature Range Tstg -55 150
* Package mounted on a ceramic board (600 0.8 )
Type Name
HM
ELECTRICAL CHARACTERISTICS (Ta=25 )
CHARACTERISTIC SYMBOL TEST CONDITION MIN. TYP. MAX. UNIT
Collector Cut-off Current ICBO VCB=40V, IE=0 - - 0.1 A
Emitter Cut-off Current IEBO VEB=4V, IC=0 - - 0.1 A
Collector-Base Breakdown Voltage V(BR)CBO IC=10 A, IE=0 60 - - V
Collector-Emitter Breakdown Voltage V(BR)CEO IC=1mA, IB=0 50 - - V
Emitter-Base Breakdown Voltage V(BR)EBO IE=10 A, IC=0 6 - - V
Collector-Emitter Saturation Voltage VCE(sat) IC=2A, IB=40mA - 100 150 mV
Base-Emitter Saturation Voltage VBE(sat) IC=2A, IB=40mA - 0.80 1.2 V
DC Current Gain hFE VCE=2V, IC=500mA 200 - 560
Transition Frequency fT VCE=10V, IC=500mA - 330 - MHz
Collector Output Capacitance Cob VCB=10V, f=1MHz - 26 - pF
