Image preview - the first page of the document
khb3d0n90p1_f1_f2


>> Download khb3d0n90p1_f1_f2 documenatation <<

Text preview - extract from the document
                                   SEMICONDUCTOR                                                     KHB3D0N90P1/F1/F2
                                                                                                                     N CHANNEL MOS FIELD
                                              TECHNICAL DATA                                                          EFFECT TRANSISTOR

  General Description                                                                                                                KHB3D0N90P1
                                                                                                             A
                                                                                                                                                         O
    This planar stripe MOSFET has better characteristics, such as fast                                                                                       C
                                                                                                                                     F
  switching time, low on resistance, low gate charge and excellent
                                                                                             E                                       G                           DIM      MILLIMETERS
  avalanche characteristics. It is mainly suitable for electronic ballast and                                                                B
                                                                                                                                                                  A               _
                                                                                                                                                                             9.9 + 0.2
                                                                                                                                                                 B         15.95 MAX
  switch mode power supplies.                                                                                                        Q                           C        1.3+0.1/-0.05
                                                                                             I                                                                   D               _
                                                                                                                                                                             0.8 + 0.1
                                                                                                                                                                 E                _
                                                                                                                                                                              3.6 + 0.2
                                                                                             K                                                           P        F               _
                                                                                                                                                                             2.8 + 0.1
                                                                                                         M                                                       G               3.7
                                                                                                                                 L
                                                                                                                                                                          0.5+0.1/-0.05
  FEATURES                                                                                                                                   J
                                                                                                                                                                 H
                                                                                                                                                                  I              1.5
                                                                                                 D                                                                J               _
                                                                                                                                                                           13.08 + 0.3
    VDSS= 900V, ID= 3A                                                                                                                                       H   K             1.46
                                                                                                         N       N
                                                                                                                                                                                _
                                                                                                                                                                            1.4 + 0.1
    Drain-Source ON Resistance                                                                                                                                    L
                                                                                                                                                                                 _
                                                                                                                                                                 M          1.27 + 0.1
    : RDS(ON)=4.5       @VGS = 10V                                                                                                                               N               _
                                                                                                                                                                            2.54 + 0.2
                                                                                                                                                                 O              _
                                                                                                                                                                            4.5 + 0.2
    Qg(typ.) = 25nC                                                                                  1       2       3                   1. GATE                  P              _
                                                                                                                                                                            2.4 + 0.2
                                                                                                                                         2. DRAIN                Q              _
                                                                                                                                                                            9.2 + 0.2
                                                                                                                                         3. SOURCE




  MAXIMUM RATING (Tc=25                   )                                                                                              TO-220AB

                                                                 RATING
                                                                                                                                     KHB3D0N90F1
              CHARACTERISTIC                  SYMBOL               KHB3D0N90F1 UNIT                                                                          C
                                                                                                             A
                                                       KHB3D0N90P1
                                                                   KHB3D0N90F2




                                                                                                                                 F



                                                                                                                                                 O
   Drain-Source Voltage                        VDSS                900             V     E                                                                            DIM    MILLIMETERS




                                                                                                                                     B
                                                                                                                                                                      A              _
                                                                                                                                                                              10.16 + 0.2




                                                                                                                                 G
                                               VGSS                                                                                                                                  _
   Gate-Source Voltage                                              30             V                                                                                  B       15.87 + 0.2
                                                                                                                                                                      C             _
                                                                                                                                                                               2.54 + 0.2
                                                                                                                                                                      D            _
                                                                                                                                                                               0.8 + 0.1
                         @TC=25                 ID         3.0             3.0*                                                                                       E              _
                                                                                                                                                                                3.18 + 0.1
   Drain Current                                                                   A
                                                                                         K




                                                                                                                                                                      F            _
                                                                                                                                                                               3.3 + 0.1
                         Pulsed (Note1)         IDP        12              12*                                                                                        G              _
                                                                                                                                                                              12.57 + 0.2
                                                                                             L                   M
                                                                                                                                                             R        H            _
                                                                                                                                                                               0.5 + 0.1
   Single Pulsed Avalanche Energy              EAS
                                                                                                                                         J                            J       13.0 MAX
                                                                   450            mJ                                                                                                _
   (Note 2)                                                                                  D
                                                                                                                                                                      K        3.23 + 0.1
                                                                                                                                                                      L       1.47 MAX
   Repetitive Avalanche Energy                 EAR                                                                                                                    M       1.47 MAX
                                                                   13             mJ                     N       N                                   H
                                                                                                                                                                      N             _
                                                                                                                                                                               2.54 + 0.2
   (Note 1)                                                                                                                                                                         _
                                                                                                                                                                      O        6.68 + 0.2
   Peak Diode Recovery dv/dt                                                                                                                                          Q             _
                                                                                                                                                                                4.7 + 0.2
                                               dv/dt               4.0            V/ns                                                                                R             _
                                                                                                                                                                               2.76 + 0.2
   (Note 3)
                                                                                         Q




                                                                                                     1       2       3
                                                                                                                                             1. GATE
   Drain Power           Tc=25                            130              43      W                                                         2. DRAIN
                                                                                                                                             3. SOURCE
                                                PD
   Dissipation           Derate above25                   1.04             0.34   W/
                                                                                                                                 TO-220IS (1)
   Maximum Junction Temperature                 Tj                 150
   Storage Temperature Range                   Tstg              -55 150                                                             KHB3D0N90F2
   Thermal Characteristics                                                                                   A                                               C
                                                                                                                                 F




                                                                                         S
   Thermal Resistance, Junction-to-Case        RthJC      0.96             2.9     /W
                                                                                                                                                 P




                                                                                             E                                                                   DIM        MILLIMETERS
   Thermal Resistance, Junction-to-                                                                                                                               A              _
                                                                                                                                                                            10.0 + 0.3
                                                                                                                                     B




                                               RthJA      62.5             62.5    /W                                                                             B              _
                                                                                                                                 G




                                                                                                                                                                            15.0 + 0.3
   Ambient                                                                                                                                                        C              _
                                                                                                                                                                            2.70 + 0.3
                                                                                                                                                                  D       0.76+0.09/-0.05
  * : Drain current limited by maximum junction temperature.                                                                                                      E            3.2 +0.2
                                                                                                                                                                                      _
                                                                                                 L                           L                                    F                _
                                                                                                                                                                               3.0 + 0.3
                                                                                         K




                                                                                                                                                             R
                                                                                                                                                                  G                _ 0.3
                                                                                                                                                                              12.0 +
  PIN CONNECTION                                                                                                         M                                        H         0.5+0.1/-0.05
                                                                                                                                     J




                                                                                                 D                       D                                        J                _
                                                                                                                                                                              13.6 + 0.5
                    D                                                                                                                                             K                _
                                                                                                                                                                               3.7 + 0.2
                                                                                                                                                                  L         1.2+0.25/-0.1
                                                                                                                                                                  M         1.5+0.25/-0.1
                                                                                                         N       N                                           H    N               _
                                                                                                                                                                             2.54 + 0.1
                                                                                                                                                                  P               _
                                                                                                                                                                              6.8 + 0.1
                                                                                                                                                                  Q               _
                                                                                                                                                                              4.5 + 0.2
                                                                                                                                                                  R               _
                                                                                                                                                                              2.6 + 0.2
                                                                                                                                                                              0.5 Typ
                                                                                                                                 Q




                                                                                                     1       2       3                                            S
       G                                                                                                                                         1. GATE
                                                                                                                                                 2. DRAIN
                                                                                                                                                 3. SOURCE



                    S                                                                                                                TO-220IS



2007. 9. 10                       Revision No : 0                                                                                                                                            1/7
                                                       KHB3D0N90P1/F1/F2

 ELECTRICAL CHARACTERISTICS (Tc=25                               )

                CHARACTERISTIC                          SYMBOL                     TEST CONDITION             MIN.   TYP.   MAX.   UNIT

   Static
   Drain-Source Breakdown Voltage                         BVDSS             ID=250 A, VGS=0V                  900     -       -     V
   Breakdown Voltage Temperature Coefficient            BVDSS/ Tj           ID=250 A, Referenced to 25         -      1       -    V/
   Gate Threshold Voltage                                      Vth          VDS=VGS, ID=250 A                 2.0     -      4.0    V
   Drain Cut-off Current                                      IDSS          VDS=900V, VGS=0V,                  -      -      10     A
   Gate Leakage Current                                       IGSS          VGS= 30V, VDS=0V                   -      -      100   nA
   Drain-Source ON Resistance                            RDS(ON)            VGS=10V, ID=1.5A                   -     4.0     4.5
   Dynamic
   Total Gate Charge                                           Qg                                              -      25     32
                                                                            VDS=720V, ID=3.0A
   Gate-Source Charge                                          Qgs                                             -      4       -     nC
                                                                            VGS=10V              (Note4, 5)
   Gate-Drain Charge                                          Qgd                                              -     11.5     -
   Turn-on Delay time                                         td(on)                                           -      31     72
   Turn-on Rise time                                            tr          VDD=450V, RG=25                    -      65    139
                                                                                                                                    ns
   Turn-off Delay time                                        td(off)       ID=3.0A              (Note4, 5)    -     104    218
   Turn-off Fall time                                           tf                                             -     127    264
   Input Capacitance                                          Ciss                                             -     820    1066
   Output Capacitance                                         Coss          VDS=25V, VGS=0V, f=1.0MHz          -      63     82     pF
   Reverse Transfer Capacitance                               Crss                                             -      9      12
   Source-Drain Diode Ratings
   Continuous Source Current                                    IS                                             -      -      3.0
                                                                            VGS
