Image preview - the first page of the document
>> Download kra107_9m documenatation <<
Text preview - extract from the document
SEMICONDUCTOR KRA107M~KRA109M
TECHNICAL DATA EPITAXIAL PLANAR PNP TRANSISTOR
SWITCHING APPLICATION.
INTERFACE CIRCUIT AND DRIVER CIRCUIT APPLICATION.
B
FEATURES
A
With Built-in Bias Resistors
Simplify Circuit Design O DIM MILLIMETERS
F
A 3.20 MAX
Reduce a Quantity of Parts and Manufacturing Process H M B 4.30 MAX
C 0.55 MAX
G
D _
2.40 + 0.15
E 1.27
F 2.30
C _
G 14.00+ 0.50
H 0.60 MAX
J 1.05
EQUIVALENT CIRCUIT BIAS RESISTOR VALUES E E
K 1.45
L 25
TYPE NO. R1(k ) R2(k )
J
M 0.80
OUT
D
K
1 2 3 N N 0.55 MAX
KRA107M 10 47 O 0.75
L
R1 KRA108M 22 47
IN 1. EMITTER
KRA109M 47 22 2. COLLECTOR
R2
3. BASE
COMMON(+)
TO-92M
MAXIMUM RATING (Ta=25 )
CHARACTERISTIC SYMBOL RATING UNIT
Output Voltage KRA107M 109M VO -50 V
KRA107M -30, 6
Input Voltage KRA108M VI -40, 7 V
KRA109M -40, 15
Output Current IO -100 mA
Power Dissipation PD 400 mW
KRA107M 109M
Junction Temperature Tj 150
Storage Temperature Range Tstg -55 150
2008. 11. 20 Revision No : 5 1/4
KRA107M~KRA109M
ELECTRICAL CHARACTERISTICS (Ta=25 )
CHARACTERISTIC SYMBOL TEST CONDITION MIN. TYP. MAX. UNIT
Output Cut-off Current KRA107M 109M IO(OFF) VO=-50V, VI=0 - - -500 nA
KRA107M 80 150 -
DC Current Gain KRA108M GI VO=-5V, IO=-10mA 80 150 -
KRA109M 70 140 -
Output Voltage KRA107M 109M VO(ON) IO=-10mA, II=-0.5mA - -0.1 -0.3 V
KRA107M - -1.2 -1.8
Input Voltage (ON) KRA108M VI(ON) VO=-0.2V, IO=-5mA - -1.8 -2.6 V
KRA109M - -3.0 -5.8
KRA107M -0.5 -0.75 -
Input Votlage (OFF) KRA108M VI(OFF) VO=-5V, IO=-0.1mA -0.6 -0.88 - V
KRA109M -1.5 -1.82 -
Transition Frequency KRA107M 109M fT * VO=-10V, IO=-5mA - 200 - MHz
KRA107M - - -0.88
Input Current KRA108M II VI=-5V - - -0.36 mA
KRA109M - - -0.16
KRA107M - 0.07 -
Rise
KRA108M tr - 0.20 -
Time
KRA109M - 0.38 -
KRA107M - 1.1 -
Switching Storage VO=-5V, VIN=-5V
KRA108M tstg - 0.3 - S
Time Time RL=1k
KRA109M - 0.7 -
KRA107M - 0.35 -
Fall
KRA108M tf - 0.4 -
Time
KRA109M - 0.48 -
KRA107M 7 10 13
Input Resistor KRA108M R1 - 15.4 22 28.6 k
KRA109M 32.9 47 61.1
KRA107M 3.7 4.7 5.7
Resistor Ratio KRA108M R2/R1 - 1.7 2.1 2.6
KRA109M 0.37 0.47 0.57
Note : * Characteristic of Transistor Only.
2008. 11. 20 Revision No : 5 2/4
KRA107M~KRA109M
I O - V I(ON) I O - V I(OFF)
KRA107M KRA107M
-100 -25
-3k
VO =-0.2V VO =-5V
25
OUTPUT CURRENT I O (mA)
-50
OUTPUT CURRENT I O (◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
