Image preview - the first page of the document
>> Download krc407v_5F409v documenatation <<
Text preview - extract from the document
SEMICONDUCTOR KRC407V~KRC409V
TECHNICAL DATA EPITAXIAL PLANAR NPN TRANSISTOR
SWITCHING APPLICATION.
INTERFACE CIRCUIT AND DRIVER CIRCUIT APPLICATION.
E
FEATURES B
With Built-in Bias Resistors
Simplify Circuit Design
2 DIM MILLIMETERS
Reduce a Quantity of Parts and Manufacturing Process A _
1.2 +0.05
D
G
A
B _
0.8 +0.05
High Packing Density.
H
1 3 _
C 0.5 + 0.05
K
D _
0.3 + 0.05
E _
1.2 + 0.05
G _
0.8 + 0.05
P P H 0.40
J _
0.12 + 0.05
EQUIVALENT CIRCUIT BIAS RESISTOR VALUES K _
0.2 + 0.05
P 5
TYPE NO. R1(k ) R2(k )
C
OUT
J
KRC407V 10 47
R1 KRC408V 22 47
IN 1. COMMON (EMITTER)
2. IN (BASE)
R2 KRC409V 47 22
3. OUT (COLLECTOR)
COMMON
VSM
MAXIMUM RATING (Ta=25 )
CHARACTERISTIC SYMBOL RATING UNIT
Output Voltage KRC407V 409V VO 50 V
KRC407V 30, -6
Input Voltage KRC408V VI 40, -7 V
KRC409V 40,-15
Output Current IO 100 mA
Power Dissipation PD 100 mW
KRC407V 409V
Junction Temperature Tj 150
Storage Temperature Range Tstg -55 150
MARK SPEC Marking
Type Name
TYPE KRC407V KRC408V KRC409V
MARK NH NI NJ
2001. 7. 24 Revision No : 0 1/4
KRC407V~KRC409V
ELECTRICAL CHARACTERISTICS (Ta=25 )
CHARACTERISTIC SYMBOL TEST CONDITION MIN. TYP. MAX. UNIT
Output Cut-off Current KRC407V 409V IO(OFF) VO=50V, VI=0 - - 500 nA
KRC407V 80 150 -
DC Current Gain KRC408V GI VO=5V, IO=10mA 80 150 -
KRC409V 70 140 -
Output Voltage KRC407V 409V VO(ON) IO=10mA, II=0.5mA - 0.1 0.3 V
KRC407V - 1.2 1.8
Input Voltage (ON) KRC408V VI(ON) VO=0.2V, IO=5mA - 1.8 2.6 V
KRC409V - 3.0 5.8
KRC407V 0.5 0.75 -
Input Votlage (OFF) KRC408V VI(OFF) VO=5V, IO=0.1mA 0.6 0.88 - V
KRC409V 1.5 1.82 -
Transition Frequency KRC407V 409V fT * VO=10V, IO=5mA - 200 - MHz
KRC407V - - 0.88
Input Current KRC408V II VI=5V - - 0.36 mA
KRC409V - - 0.16
KRC407V - 0.05 -
Rise
KRC408V tr - 0.12 -
Time
KRC409V - 0.26 -
KRC407V - 2.0 -
Switching Storage VO=5V, VIN=5V
KRC408V tstg - 2.4 - S
Time Time RL=1k
KRC409V - 1.5 -
KRC407V - 0.36 -
Fall
KRC408V tf - 0.4 -
Time
KRC409V - 0.41 -
Note : * Characteristic of Transistor Only.
2001. 7. 24 Revision No : 0 2/4
KRC407V~KRC409V
I O - V I(ON) I O - V I(OFF)
KRC407V KRC407V
50 3k
-25 25
OUTPUT CURRENT I O (mA)
30 VO =0.2V
100
