               DTC114YE/DTC114YUA/DTC114YKA/DTC114YSA/DTC114YCA




DIGITAL TRANSISTOR (NPN)
FEATURES
1. Built-in bias resistors enable the configuration of an inverter circuit without
   connecting external input resistors(see equivalent circuit).
2. The bias resistors consist of thin-film resistors with complete isolation to allow
   negative biasing of the input. They also have the advantage of almost completely
   eliminating parasitic effects.
3. Only the on/off conditions need to be set for operation, making device design easy.



PIN CONNENCTIONS AND MARKING

 DTC114YE                                                 DTC114YUA




     SOT-523      Addreviated symbol: 64                      SOT-323     Addreviated symbol: 64


                                                          DTA114ECA
                                                          DTC114YCA
 DTC114YKA


   SOT-23
 SOT-23-3L
                    Addreviated symbol: 64                SOT-23        Addreviated symbol: 64



 DTC114YSA




 TO-92S




 1




 JinYu                                       www.htsemi.com
 semiconductor

                                                                                                   Date:2011/05
                 DTC114YE/DTC114YUA/DTC114YKA/DTC114YSA/DTC114YCA
Absolute maximum ratings(Ta=25)
                                                                        Limits (DTC114Y )
                Parameter               Symbol                                                                           Unit
                                                          E       UA           KA           CA                     SA
Supply voltage                            VCC                                  50                                         V
Input voltage                             VIN                                -6to+40                                      V
                                           IO                                  70                                        mA
Output current
                                         IC(Max.)                             100                                        mA
Power dissipation                          PC             150                 200                                  300   mW
Junction temperature                       Tj                                 150

Storage temperature                       Tstg                             -55 to+ 150

Electrical characteristics (Ta=25)
       Parameter            Symbol     Min.         Typ         Max.         Unit                  Conditions
                             VI(off)                              0.3                            VCC=5V ,IO=100
