Image preview - the first page of the document
>> Download irf840lcspbf_irf840lclpbf documenatation <<
Text preview - extract from the document
PD- 95759
IRF840LCSPbF
IRF840LCLPbF
Lead-Free
8/24/04
Document Number: 91068 www.vishay.com
1
IRF840LCS/LPbF
Document Number: 91068 www.vishay.com
2
IRF840LCS/LPbF
Document Number: 91068 www.vishay.com
3
IRF840LCS/LPbF
Document Number: 91068 www.vishay.com
4
IRF840LCS/LPbF
Document Number: 91068 www.vishay.com
5
IRF840LCS/LPbF
Document Number: 91068 www.vishay.com
6
IRF840LCS/LPbF
Document Number: 91068 www.vishay.com
7
IRF840LCS/LPbF
D2Pak Package Outline
Dimensions are shown in millimeters (inches)
D2Pak Part Marking Information
T HIS IS AN IRF 530S WIT H PART NUMB ER
LOT CODE 8024 INT E RNAT IONAL
AS S EMB LED ON WW 02, 2000 RE CT IF IER F 530S
IN T HE AS S EMB LY LINE "L" LOGO
DAT E CODE
Note: "P" in as s embly line YE AR 0 = 2000
pos ition indicates "Lead-F ree" AS S E MBLY
LOT CODE WE EK 02
LINE L
OR
PART NUMB ER
INTE RNATIONAL
RECT IFIER F530S
LOGO
DATE CODE
P = DES IGNATE S L EAD-FRE E
AS S EMB L Y PRODUCT (OPTIONAL)
LOT CODE YE AR 0 = 2000
WE EK 02
A = AS S EMB LY S IT E CODE
Document Number: 91068 www.vishay.com
8
IRF840LCS/LPbF
TO-262 Package Outline
Dimensions are shown in millimeters (inches)
TO-262 Part Marking Information
EXAMPLE: T HIS IS AN IRL3103L
LOT CODE 1789 PART NUMBER
INT ERNAT IONAL
AS S EMBL ED ON WW 19, 1997
RECT IFIER
IN T HE AS S EMBLY LINE "C" LOGO
Note: "P" in as sembly line DAT E CODE
pos ition indicates "Lead-Free" YEAR 7 = 1997
AS S EMBLY
LOT CODE WEEK 19
LINE C
OR
PART NUMBER
INT ERNAT IONAL
RECT IF IER
L OGO
DAT E CODE
P = DES IGNAT ES LEAD-FREE
AS S EMBLY PRODUCT (OPT IONAL)
LOT CODE YEAR 7 = 1997
WEEK 19
A = AS S EMBLY S IT E CODE
Document Number: 91068 www.vishay.com
9
IRF840LCS/LPbF
D2Pak Tape & Reel Information
Dimensions are shown in millimeters (inches)
TRR
1.60 (.063)
1.50 (.059)
1.60 (.063)
4.10 (.161) 1.50 (.059)
3.90 (.153) 0.368 (.0145)
0.342 (.0135)
FEED DIRECTION 1.85 (.073) 11.60 (.457)
1.65 (.065) 11.40 (.449) 24.30 (.957)
15.42 (.609)
23.90 (.941)
15.22 (.601)
TRL
1.75 (.069)
10.90 (.429) 1.25 (.049)
10.70 (.421) 4.72 (.136)
16.10 (.634) 4.52 (.178)
15.90 (.626)
FEED DIRECTION
13.50 (.532) 27.40 (1.079)
12.80 (.504) 23.90 (.941)
4
330.00 60.00 (2.362)
(14.173) MIN.
MAX.
30.40 (1.197)
NOTES : MAX.
1. COMFORMS TO EIA-418. 26.40 (1.039) 4
2. CONTROLLING DIMENSION: MILLIMETER. 24.40 (.961)
3. DIMENSION MEASURED @ HUB.
3
4. INCLUDES FLANGE DISTORTION @ OUTER EDGE.
