Image preview - the first page of the document
>> Download irfr9014pbf_irfu9014pbf documenatation <<
Text preview - extract from the document
PD- 95383A
IRFR9014PbF
IRFU9014PbF
Lead-Free
12/07/04
Document Number: 91277 www.vishay.com
1
IRFR/U9014PbF
Document Number: 91277 www.vishay.com
2
IRFR/U9014PbF
Document Number: 91277 www.vishay.com
3
IRFR/U9014PbF
Document Number: 91277 www.vishay.com
4
IRFR/U9014PbF
Document Number: 91277 www.vishay.com
5
IRFR/U9014PbF
Document Number: 91277 www.vishay.com
6
IRFR/U9014PbF
Document Number: 91277 www.vishay.com
7
IRFR/U9014PbF
D-Pak (TO-252AA) Package Outline
Dimensions are shown in millimeters (inches)
D-Pak (TO-252AA) Part Marking Information
EXAMPLE: THIS IS AN IRFR120
PART NUMBER
WITH ASSEMBLY INT ERNAT IONAL
LOT CODE 1234 RECTIF IER IRFU120 DAT E CODE
AS SEMBLED ON WW 16, 1999 LOGO 916A YEAR 9 = 1999
IN T HE ASS EMBLY LINE "A" 12 34 WEEK 16
LINE A
Note: "P" in as sembly line pos ition AS SEMBLY
indicates "Lead-F ree" LOT CODE
OR
PART NUMBER
INTERNAT IONAL
RECT IFIER IRFU120 DATE CODE
LOGO P = DESIGNAT ES LEAD-FREE
PRODUCT (OPT IONAL)
12 34
YEAR 9 = 1999
ASS EMBLY WEEK 16
LOT CODE
A = ASSEMBLY S ITE CODE
Document Number: 91277 www.vishay.com
8
IRFR/U9014PbF
I-Pak (TO-251AA) Package Out (lineDimensions are shown in millimeters (inches)
I-Pak (TO-251AA) Part Marking Information
EXAMPLE: T HIS IS AN IRFU120 PART NUMBER
INT ERNAT IONAL
WIT H AS SEMBLY
RECT IFIER IRFU120 DAT E CODE
LOT CODE 5678
LOGO 919A YEAR 9 = 1999
AS SEMB LED ON WW 19, 1999
56 78 WEEK 19
IN T HE AS SEMB LY LINE "A"
LINE A
ASS EMBLY
Note: "P" in assembly line
LOT CODE
position indicates "Lead-F ree"
OR
PART NUMB ER
INT ERNAT IONAL
RECT IFIER IRF U120 DAT E CODE
LOGO P = DESIGNAT ES LEAD-FREE
56 78 PRODUCT (OPT IONAL)
YEAR 9 = 1999
ASS EMB LY WEEK 19
LOT CODE A = AS SEMBLY S IT E CODE
Document Number: 91277 www.vishay.com
9
IRFR/U9014PbF
D-Pak (TO-252AA) Tape & Reel Information
Dimensions are shown in millimeters (inches)
TR TRR TRL
16.3 ( .641 ) 16.3 ( .641 )
15.7 ( .619 ) 15.7 ( .619 )
12.1 ( .476 ) FEED DIRECTION 8.1 ( .318 )
FEED DIRECTION
11.9 ( .469 ) 7.9 ( .312 )
NOTES :
1. CONTROLLING DIMENSION : MILLIMETER.
2. ALL DIMENSIONS ARE SHOWN IN MILLIMETERS ( INCHES ).
3. OUTLINE CONFORMS TO EIA-481 & EIA-541.
13 INCH
16 mm
NOTES :
1. OUTLINE CONFORMS TO EIA-481.
Data and specifications subject to change without notice.
IR WORLD HEADQUARTERS: 233 Kansas St., El Segundo, California 90245, USA Tel: (310) 252-7105
TAC Fax: (310) 252-7903
12/04
Document Number: 91277 www.vishay.com
10
