Image preview - the first page of the document



>> Download irgs14b40l documenatation <<

Text preview - extract from the document

                                                             PROVISIONAL
                                                                                        IRGS14B40L
INSULATED GATE BIPOLAR TRANSISTOR                                                               14A, Voltage Clamped
                                                                                                           400V IGBT

                                            Co l l ect o r




               G at e            Rg


                                     Rg e




                                             Em it te r                                 D 2 P ak

                                                                     MIN   TYP MAX      UNITS          CONDITIONS
VCL         COLLECTOR - EMITTER CLAMPING VOLTAGE                     370   400 430      V              RG =1 kOhm , Ic =7A
VECAV       EMITTER - COLLECTOR AVALANCHE VOLTAGE                    24    30           V              Ic = -10mA, 25 C
VGE(TH)     GATE - EMITTER THRESHOLD VOLTAGE                         0.75 1.8     2.2   V              Ic = 1 mA
I C25       CONTINUOUS COLLECTOR CURRENT                                          18    A              VGE = 5V, 25 C
IC100       CONTINUOUS COLLECTOR CURRENT                                          14    A              VGE = 5V, 100 C
VGE         GATE - EMITTER VOLTAGE                                   -10          10    V
TJ          OPERATING JUNCTION TEMPERATURE RANGE                     -40          175   C

VESD        ELECTROSTATIC VOTAGE FROM

            EACH PIN TO EACH OF THE OTHER PINS                       -6           6     kV             C= 100pF, R = 1.5 kOhms
ISCIS25C    SELF CLAMPED INDUCTIVE SWITCHING CURRENT                 24                 A              0.7mH INDUCTANCE, 25 C
                                                                     14                 A              2.2mH INDUCTANCE, 25 C
                                                                     10                 A              4.7mH INDUCTANCE, 25 C
ISCIS100C   SELF CLAMPED INDUCTIVE SWITCHING CURRENT                 13                 A              1.5mH INDUCTANCE, 150 C
                                                                     7.5                A              4.7mH INDUCTANCE, 150 C
                                                                     5.5                A              8.7mH INDUCTANCE, 150 C
t sc        SHORT CIRCUIT WITHSTAND TIME                             750                us             Tc = 150 C
R1          GATE SERIES RESISTANCE                                         75           Ohms
R2          GATE EMITTER RESISTANCE                                        20           k Ohms
VCE(ON)     COLLECTOR - EMITTER SATURATION VOLTAGE                         1.55         V              Ic= 7A, VGE =5V, 25C
                                                                           1.8          V              Ic = 10A, VGE =5V, 25C
                                                                                        O
R qJC       THERMAL RESISTANCE, JUNCTION TO CASE                                  1.5       K / WATT

RqJA        THERMAL RESISTANCE,JUNCTION TO AMBIENT

                                                                                        O
            (PCB MOUNTED, STEADY STATE )                                          40        K / WATT




                                                                                                                                 11-4-98
IRGS14
Electrical Characteristics @ TJ = 25
