Image preview - the first page of the document



>> Download irhf57034 documenatation <<

Text preview - extract from the document

                                                                                                    PD - 93791




RADIATION HARDENED                                                                       IRHF57034
POWER MOSFET                                                                         60V, N-CHANNEL
THRU-HOLE (TO-39)                                                                    R5
                                                                                              TECHNOLOGY

Product Summary
 Part Number Radiation Level              RDS(on)    ID
 IRHF57034    100K Rads (Si)              0.048     12*A
 IRHF53034   300K Rads (Si)               0.048     12*A
 IRHF54034           600K Rads (Si)        0.048    12*A
 IRHF58034         1000K Rads (Si)         0.060    12*A
                                                                                        TO-39
International Rectifier's R5TM technology provides         Features:
high performance power MOSFETs for space appli-            n   Single Event Effect (SEE) Hardened
cations. These devices have been characterized for         n   Ultra Low RDS(on)
Single Event Effects (SEE) with useful performance         n   Neutron Tolerant
up to an LET of 80 (MeV/(mg/cm2)). The combination         n   Identical Pre- and Post-Electrical Test Conditions
of low RDS(on) and low gate charge reduces the power       n   Repetitive Avalanche Ratings
losses in switching applications such as DC to DC          n    Dynamic dv/dt Ratings
converters and motor control. These devices retain         n   Simple Drive Requirements
all of the well established advantages of MOSFETs          n   Ease of Paralleling
such as voltage control, fast switching, ease of paral-    n   Hermetically Sealed
leling and temperature stability of electrical param-
eters.
Absolute Maximum Ratings                                                                        Pre-Irradiation
                                  Parameter                                                                   Units
ID @ VGS = 12V, TC = 25
