Image preview - the first page of the document



>> Download irhf57234se documenatation <<

Text preview - extract from the document

                                                                                                      PD - 93831




RADIATION HARDENED                                                                IRHF57234SE
POWER MOSFET                                                                     250V, N-CHANNEL
THRU-HOLE (TO-39)                                                                   R5
                                                                                             TECHNOLOGY



Product Summary
 Part Number Radiation Level            RDS(on)      ID
 IRHF57234SE 100K Rads (Si)             0.42        5.4A


                                                                                       TO-39
International Rectifier's R5TM technology provides
high performance power MOSFETs for space appli-            Features:
cations. These devices have been characterized for         n   Single Event Effect (SEE) Hardened
Single Event Effects (SEE) with useful performance         n   Ultra Low RDS(on)
up to an LET of 80 (MeV/(mg/cm2)). The combination
                                                           n   Neutron Tolerant
of low RDS(on) and low gate charge reduces the power       n   Identical Pre- and Post-Electrical Test Conditions
losses in switching applications such as DC to DC          n   Repetitive Avalanche Ratings
converters and motor control. These devices retain         n    Dynamic dv/dt Ratings
all of the well established advantages of MOSFETs
                                                           n   Simple Drive Requirements
such as voltage control, fast switching, ease of paral-
                                                           n   Ease of Paralleling
leling and temperature stability of electrical param-
                                                           n   Hermetically Sealed
eters.


Absolute Maximum Ratings                                                                      Pre-Irradiation
                                 Parameter                                                                   Units
ID @ VGS = 12V, TC = 25
