>> Download ixgk35n120b_ixgk35n120bd1_ixgx35n120b_ixgx35n120bd1 documenatation <<Text preview - extract from the document Preliminary Data Sheet
HiPerFASTTM IGBT IXGK 35N120B VCES = 1200 V
IXGX 35N120B IC25 = 70 A
IXGK 35N120BD1 VCE(sat) = 3.3 V
IXGX 35N120BD1 tfi(typ) = 160 ns
(D1)
Symbol Test Conditions Maximum Ratings TO-264 AA (IXGK)
VCES TJ = 25
