Image preview - the first page of the document
ixgr32n60cd1


>> Download ixgr32n60cd1 documenatation <<

Text preview - extract from the document
HiPerFASTTM IGBT                                      IXGR 32N60CD1                         VCES                     = 600 V
with Diode                                                                                  IC25                     = 45 A
ISOPLUS247TM                                                                                VCE(SAT)                 = 2.7 V
                                                                                            tfi(typ)                 = 55 ns
(Electrically Isolated Backside)


Preliminary data sheet


Symbol         Test Conditions                                    Maximum Ratings         ISOPLUS 247TM (IXGR)
                                                                                              E 153432
VCES           TJ = 25
